This article applies to:

D1 and D1 Pro

Issue Description

If you use the rotary attachment, and the engraved image is flipped horizontally compared with the designed image, please refer to this article for troubleshooting.

#1 Check the Placement

Make sure the rotary is placed in the way shown in the below photo.

#2 Check the Lightburn Setting

If you are using Lightburn, enable the rotary attachment and the mirror output.

#3 Check the XCS Reflect Setting

Before processing, check the direction of the image. If it's flipped, check if the Reflect mode is enabled.
